Rays Gram Lights 57XR - 17"
Rays Gram Lights 57XR - 17"
SKU:
Couldn't load pickup availability
The Third R model.
57CR and 57DR has been supported not only in D1GP and FORMULA DRIFT but also in various race scenes. This time, 57XR joins the royal “R” series as the third model. 57XR is structured by 2×6 slender spokes which design is authentic, while the machining logo on the spoke side creates an accent by painting to make it an embossed logo. And, the unique design of the spokes over the rim flange has been adopted. There are no exceptions on performance. The knurling finish has also been applied for all sizes to reduce tire slippage to the wheel. In addition, for 18inch 9 1/2J, 10 1/2J and 19inch 10 1/2J, the EH2+ Hump has been employed to minimize the risk of bead dropping, which is an adverse effect of lower tire pressure in drifting. 57XR debuts for one of the appropriate “R” series by its performance and design.
Features
Spec
57XR
17inch/18inch/19inch
Cast 1pc. Wheel
Knurling finish
EH2+ hump for 17x9J、18×9 1/2J 、18×10 1/2J、19×10 1/2J
JWL+R Spec 1
Dark Bronze(Z2)
Matte Graphite(MF)
-
No.21 INSIDE ALUMINUM AIR VALVE BK
Size / Spec
Caution
※Scheduled to be discontinued once inventory clears.
・5H-P.C.D.108/112/120: Cannot fit Volvo (XC90 Plug-in Hybrid), Mercedes Benz (GL Class, GLS Class, R350 4 Matic 2012-, R550 4 Matic, ML63 4Matic, S550 Plug-in Hybrid, V class [W447], GLE63S 4Matic, EQC400), Bentley, Maybach (57, 62), BMW (X5 7seater, X5 PHV, X5 [F15], X6 Active Hybrid, X7), Land Rover (only for 5H-120), Rolls-Royce, Tesla (Model X).
※ * ：Tuner size. (Tire and or wheel may interfere or protrude from the body/fender on normal based vehicles.
・Hub clearance is the measurement to the center cap attachment. Measurements will differ depending on the center cap used.
[ CALIPER CLEARANCE ]
▼： IMPREZA (GDB 4POT)
▽： IMPREZA (GDB & GRB 4POT)
Θ： WRX STI (4POT)
η： WRX STI (6POT)
■： IS, GS, RC, CROWN (210), MARK-X (3.5L)
⊿： IS-F
◎： RC-F
＃： SILVIA (S15)
△： SKYLINE (R34GT-R, CPV35, CKV36, HV37, RV37/400R)
▲： SKYLINE (R34 GT-R)
□： SKYLINE (CKV36, HV37, RV37/400R)
α： SKYLINE (CKV36, HV37), FUGA(Y51)
β： SKYLINE (HV37)
γ： SKYLINE (CPV35)
○： FAIRLADY Z (Z33, Z34, RZ34)
●： FAIRLADY Z (Z34)
Ω： FAIRLADY Z (Z33)
☆： LANCER EVO.(VII～IX, X)
★： LANCER EVO.X
∑： LANCER EVO.(VII～IX)
◆： GT-R (R35/φ380 rotor)
◇： GT-R (R35/φ380, φ390 rotor)
〓： GR YARIS (RZ)
Ψ： ROADSTER (ND)/124 Spider Brembo
※CALIPER CLEARANCE are for reference only and do not guarantee inspection, and/or the size mandated by local authorities. Selecting sizes is by your own judgement and we recommend consulting fitments with a professional outlet.
Face Design
